    Low Temperature Jacketed Basket Centrifuge Stainless Steel Ethanol Extraction Machine

    Ask Lasest Price
    Brand Name : Peony
    Model Number : PPTD
    Certification : ISO9001& ISO14001
    Payment Terms : TT,LC, Western Union
    Supply Ability : 50sets per month
    Delivery Time : 30-60days
    • Product Details
    • Company Profile

    Low Temperature Jacketed Basket Centrifuge Stainless Steel Ethanol Extraction Machine


    Low Temperature Jacketed Centrifuge

    Stainless Steel Ethanol Extraction Machine


    Process overview


    Operator fills filter bag with milled plant material and places it in the machine.


    The centrifuge is then flooded, and bi-directional agitated for full target compound removal.

    After the wash, the plant material undergoes a medium duty spin dry till high speed spin dry to remove the liquid as much as possible.

    The alcohol wash is then collected to some container for further processing.

    Features


    - 304 and 316L Sanitary Stainless Steel Construction


    - Low temperature rating: -40c


    - Reinforced Sight Glass


    - Bi-Directional Agitation


    - Auto/Manual Controls


    - Digital HMI Interface


    - Variable Speed Control


    - Easy Material Loading/ Unloading


    - Heavy-Duty Spin Drying


    - No foundation required


    - Direct Drum type, without curl inward


    Collocation


    1. Ex proof motor

    2. Viton Seals

    3. Touch screen panel with PLC program

    4. Inverter control box

    5. On spot ex button

    6. Closed type filter bags

    7. Tri clamp fittings for feed and drain port

    8. Drum without curl inward


    Specifications


    ModelCapacity for dry ground plant(per batch)
    PPTD-25~8kgs
    PPTD-50~15kgs
    PPTD-135~30kgs
    PPTD-200~45kgs
    PPTD-300~60kgs

    Application


    It is applicable to the filtrating of suspension containing granules and also be used for the dehydration of fiber substances and especially applicable to the filtrating of materials of high viscosity and fine granules as well as toxic and flammable materials.


    It has found wide applications in such trades as chemical, pharmacy, food, light industry, etc. for example: gypsum, thiamine, mirabilite, ferric sulfate, copper sulfate, nickel sulfate, potassium chloride, acetic acid, borax, soda, rubber additive, dye, plastic raw material, soap, grease, all kinds of resins, food salt, sodium glutamate, food additives, starch sugar-making, vitamins, antibiotics, herbicide, insecticide, the dehydration of such mineral fines as copper, zinc, aluminum, etc.


    Pictures


    Low Temperature Jacketed Basket Centrifuge Stainless Steel Ethanol Extraction Machine


    Packing&Delivery


    Low Temperature Jacketed Basket Centrifuge Stainless Steel Ethanol Extraction Machine


    Customer Photo


    Low Temperature Jacketed Basket Centrifuge Stainless Steel Ethanol Extraction Machine


    Why Choose Us


    Competition


    1.Quality and experience.We are top centrifuge supplier in China,our designs and structures are analogous to world leader brands.


    2.My price is not the lowest in China ,but we promise,for the same quality and collocation,my price is the most favorable,for the same price,my quality is definately superior to other brands.


    Service

    1. 12 months guarantee period from machine arriving date.


    2. Abundant spare parts in stock are available to provide.


    3. Our technicians could be dispatched for overseas service.


    4. 7*24 hours technical consultation.


    5. Your workers could get trained both in our factory and yours.


    6. Routine tracing till the machine work properly will be done timely.


    7. We will remind you to do the normal maintenance.


    8. Your suggestions or any comments & reflection would be treated in priority.


    9. Marketing team will visit you during our visit in your country if you require.
