Model PPTD Top Discharging Basket Centrifuge for Ground Plant Washing with Alcohol

Features

1) No-base installation, without traditional tripod type hanging structure and simplifies the installation process
2) Reasonable design and new and simple structure
3) Basic platform is the work operation platform

4) Reduced labor and high efficiency
5) Simple operations and easy cleaning
6) Outside and inside surface of rotary drum is polished
7) All of fasteners are made of stainless steel
8) Transmission section is sealed with stainless steel
9) Airtight packing is made of silicone rubber
10) Equipped with CIP system, the whole machine meets GMP hygienic standards
11) Imported high-viscosity liquid damping agent shock isolator ensures that no vibrations will affect the base of the unit, the ground and neighboring equipment

12) Outer case has a fully opening cover

13) Especially suitable for solid-liquid separation of poisonous, harmful mediums
14) With open-cover, overheating, overloading and over-current protection
15) Full sealing, explosion-proof and very clean
16) Adopts explosion motor frequency driving and static-proof V-belt
17) When equipped with nitrogen protection, the machine is suitable for solid-liquid separation of combustibles or explosive

Backgrounds

It can be used topically, orally, or through inhalation. acts as an anti-inflammatory, anti-anxiety, and pain reliever without causing intoxication. The market is one of the world's fastest growing businesses and is on track to be a billion dollar industry by 2020.

Since it is about to enter the USA scene in a big way,extracting oil from plants and isolating the compound into a supplement is technically legal in many countries,till 2019,it is legalized in all 50states in USA and spread to Canada,and european countries like Swiss,UK,Poland,France,Denmark,Spain etc.

Operator fills filter bag with milled plant material and places it in the machine.The centrifuge is then flooded, and bi-directionally agitated for full target compound removal.After the wash, the plant material undergoes a medium duty spin dry till high speed spin dry to remove the liquid as much as possible.The alcohol wash is then collected to some container for further processing

Description

The PPTD centrifuge is top discharging, hermetic closure type equipment. The material is fed into the drum through the feeding pipe on the hermetic closure casing; under the action of the centrifuge force field, the liquid-phase passes through the filter medium and the discharged out of the machine, while the solid-phase material is retained inside the drum and, after the machine is stopped, the material is discharged from the top. The centrifuge has such features as smooth running, easy & convenient operation as well as conducting feeding, washing and dehydrating under the state of hermetic closure, etc.

Model PPTD flat-plate centrifuge has got rid of traditional hanging type of leg support and instead it adopts flat-plate counterweight and high-viscosity damping vibration reducer for absorbing vibration. The installation requires no foundation.

Description

The PPTD centrifuge is top discharging, hermetic closure type equipment. The material is fed into the drum through the feeding pipe on the hermetic closure casing; under the action of the centrifuge force field, the liquid-phase passes through the filter medium and the discharged out of the machine, while the solid-phase material is retained inside the drum and, after the machine is stopped, the material is discharged from the top. The centrifuge has such features as smooth running, easy & convenient operation as well as conducting feeding, washing and dehydrating under the state of hermetic closure, etc.

Specification

More pictures

Packing

Basic Information

Zhangjiagang City Peony Machinery Co., Ltd., founded as a special producing enterprise of separating equipment in 2008, is the well-known manufacturer and service provider of separation and filtration in China. Peony dedicated to solving the solid-liquid, liquid-liquid separation problems for clients all over the world and providing separating and filtering mechanical products with convenient operation, high efficiency, reliable quality, and excellent service worldwide. Being a group corporation, Peony has 3 producing bases in China - Zhangjiagang, Nanjing, and Hangzhou city.

Products

As the professional supplier of separating and filtering equipment, we produce basket centrifuges, decanters, and disc separators starch product line, and sell the auxiliary equipment such as clarify equipment, filters, pumps, etc. These 25 series of more than 150 products are self-development of Peony and have attained national patent. Those products and relevant auxiliary equipment are widely used in chemical, petroleum, pharmacy, mining, food, beverage industry, and environmental protection.

We own various kinds of inspection and testing facilities with a value over USD10million, now,16 testing tables,6920 gear testing center, X-ray detecting machine, high-speed dynamic balancing machine, ultrasonic flaw detection machines, etc, we are equipped with complete testing, inspection, analysis control system, advanced testing machines and simulative working condition test table and automatic control testing system, which guarantees our new product research, processing validation, and quality.

We have strongly equipped the robust and precise processing machines from Germany, Italy, England, and our domestic famous brand, here, I'd like to list several of them for your reference.
200 Numerical Control Boring and Milling Machine TK6920
160 Numerical Control Boring and Milling Machine TK6916
Italian PAMA Numerical Control Boring and Milling Machine
80T CNC Lathe
40 T CNC Lathe
2.5m Merry Go Round Machine C525E
Z100 Radial Drill
Numerical Controlled Vertical Milling Machine
Underwater Plasma Cutting Center
CNC Machining Center


We harvested great achievement these years, and turnover reaches to 380million RMB in
the year 2013, and we expect to carry out 500million RMB in 2015.

Welcome all who are engaged in the separation and filtration to work with us, and we are also looking for qualified world wide agents to provide better service and deep marketing.

Worldwide Network

Our products have spread all over the world and are applied over 35 countries and regions, for example, America, Germany, Italy, Sweden, Canada, Singapore, Australia, Brazil, Russia, India, Middle East, and Southeast Asia, etc. To provide flexible and qualified technical service to resolve any maintenance issue in the shortest time possible, now we have established agents in many countries such as Brazil, Colombia, Latin America, Bangladesh, Southeast Asia, etc.

Society Reward

Peony is devoting into the charity activity, we are subsidizing some poor students to finish the school and are trying to set up some primary to feedback the society, hereby, we appeal to all people to enter into the charity activity, technical innovation changes the world, love embraces the world!
