    Continuous Drilling Mud Centrifuge Industrial Auto Sludge Dewatering Decanter Centrifuge

    Ask Lasest Price
    Brand Name : Peony
    Certification : ISO9001& ISO14001
    Model Number : PDC
    Delivery Time : 60-75days
    Payment Terms : TT, LC
    Supply Ability : 60sets per month
    • Product Details
    • Company Profile

    Continuous Drilling Mud Centrifuge Industrial Auto Sludge Dewatering Decanter Centrifuge

    TreatmentContinuous Drilling Mud Centrifuge Industrial Auto Sludge Dewatering Decanter Centrifuge


    Description


    The processing of crude oil in refineries and petrochemical plants creates oil contaminated waste water. Processing this waste water signifies
    separating the waste water into its main components consisting of oil, water and solids. Due to the increasing significance of oil, the objective
    lies in recovering as much oil as possible and in disposing other components like water and solids in an efficient way.


    Decanters with slow rotation speeds are normally based on horizontal separation technology. Decanter eusure optimum separation efficiency in the case of suspensions with a very high proportion of solid. They are also used for the extraction constituents from liquids and for concentrating, dewatering and classfying solids.


    Continuous Drilling Mud Centrifuge Industrial Auto Sludge Dewatering Decanter Centrifuge


    Decanter design:

    Type: 2- phase separation

    Materials: use high-quality stainless steel for all product wetted areas.

    Bearings: SKF brand. A special selection and arrangement of bearings provides for long life and exceptional reliability.

    Wear protection: welded hard facing or spray coating, ceramic technology.


    Specifications


    Model

    Diameter

    (mm)

    Bowl Speed

    (rpm)

    G-force

    Capacity

    (m3/h)

    Main Power

    (kw)

    Weight

    (kg)

    Overall Size

    (L × W × H)

    (mm)

    PNX-409250550034930.2~215/410202500 × 650 × 760

    PNX-414

    355400031751~1018.5/7.52035

    2765 × 920 × 1060

    PNX-41635540003175

    1~15

    18.5/7.52122

    3065 × 920 × 1060

    PNX-41835540003175

    1~25

    22/7.52222

    3365 × 920 × 1060

    PDC-16.542030002113

    10~30

    55/154600

    4080 ×1100 × 1420

    PDC-17-442036003042

    3~15

    30/7.55165

    3331 × 990 × 1066

    PDC-18-4.445033002739

    10~20

    37/112739

    4000 × 1120 × 1239

    PDC-2050032002860

    5~45

    55/114400

    4489 × 1160 × 1350

    PDC-2154028002366

    15~50

    45/155290

    4587 × 1285 × 1368

    PDC-2462032003555

    15~60

    Hydraulic station 90

    8000

    4650 × 2010× 1200

    PDC-28HH72022001975

    15-80

    110/379393

    4800 ×1350 × 1500


    Competitive Advantages

    • automatic continuous operation
    • Water level adjustable
    • Highest efficiency and lowest power consumption
    • PLC control
    • Screw conveyor full tiled.

    Applications


    Drilling mud is an integral part of most drilling operations,it is also called drilling fluid, there are some solids suspended in the fluid.


    Peony Decanter Centrifuge can provide solid-liquid separation technology to your drilling mud application, enabling reuse of the material and more efficient and cost-effective disposal.We have our special design and collocation decanter centrifuge for oilfield and industrial solids control, drilling fluid / mud cleaning and process water treatment.

    Peony Decanter centrifuges are used to process water-based and oil-based drilling fluids. Oilfield decanter centrifuges mechanically increase the gravitational force exerted on the liquid and solids mixture present in the mud system. We can apply over 3,000 G-forces machine to separate the particles in the fluid.


    Peony Decanter centrifuges have wide process capacity to meet all ranges as per drilling program.It is commonly and widely used used for oilfield and gas well operations providing efficient solids control while significantly reducing the operator's total mud cost and minimize waste disposal volumes.


    Gravity separation


    On account of difference in density, the mixed liquid in the container, after a period of time, is gradually divided into 2 layers. The heavy phase particle of the mixed liquid deposits to the bottom of the container, while the light phase one suspends to the upper surface. A rather distinctive dividing plane forms between the light and heavy phases. The separation speed is affected by the difference in density between the light and heavy phases that make up the mixed liquid. The larger the difference in density is, the faster the separation speed will be.


    More pictures


    Continuous Drilling Mud Centrifuge Industrial Auto Sludge Dewatering Decanter Centrifuge

    Continuous Drilling Mud Centrifuge Industrial Auto Sludge Dewatering Decanter Centrifuge


    Continuous Drilling Mud Centrifuge Industrial Auto Sludge Dewatering Decanter Centrifuge


    Processing equipment

    Continuous Drilling Mud Centrifuge Industrial Auto Sludge Dewatering Decanter Centrifuge

    Guarantee


    Peony Centrifuge has been dedicated to producing machinery and equipments and carrying out facility construction, pursuing the best quality and producing the best product at the same time. We are committed to reward you with a better quality in return for our interest in and faith toward. We will do our utmost for one more stepping forward, based on our infinite services and trust to customers.
