    3 Phase Oil Centrifuge Machine Fuel Oil Hadling System Disc Diesel Oil Centrifuge

    Ask Lasest Price
    Brand Name : Peony
    Model Number : PDSD14000
    Certification : CCS, ISO
    Payment Terms : TT, LC
    Supply Ability : 100sets per month
    Delivery Time : 75days after down payment
    • Product Details
    • Company Profile

    3 Phase Oil Centrifuge Machine Fuel Oil Hadling System Disc Diesel Oil Centrifuge

    3 Phase Oil Centrifuge Machine Fuel Oil Hadling System Disc Diesel Oil Centrifuge


    Description


    PDSD14000 unit is mainly used to remove water and mechanical impurities from oil, so as to reduce wear of the diesel engine and other machine, and prolong engine life. The model is also used to separate two unsolvable liquids with different specific gravity or remove small amount of solid particle from liquid.


    The machine adopts automatic control, and has the advantages of high efficiency, low oil consumption, convenient operation and economic maintenance cost.


    The clear oil and dirty water are pumped out by centripetal pump, the sludge is discharged automatically and fully.


    The machine is one kind of rotary machine with high speed. After accurate dynamic balancing, it can run for long time with low vibration, safety and security.


    3 Phase Oil Centrifuge Machine Fuel Oil Hadling System Disc Diesel Oil Centrifuge


    Advantages


    1. Moisture sensor(No-gravity ring) technology is adopted to ensure the quality of the oil after separation.
    2. Bowl with full hydraulic structure brings more thorough slage discharge, more stable and reliable performance.
    3. The new type seamless belt drive(No second tensioning required) brings more reliable structure and more simplified mechanical structure.
    4. High rotating speed ensure the best separation effect.
    5. Our separator is with low power consumption and light weight, which is in accordance with the requirements of the national industry.


    Main Technical Specification


    Discharging type

    Variable discharging
    RatedcapacityL/h14000(0# diesel oil)
    Rotating speedRPM7800
    Output pressure of clear oilMpa≤0.2
    Output pressure of sewageMpa≤0.3
    Motor powerKw22
    Full volume of the slag cavityL2

    Other oil capacity reference chart


    Oil types

    Fuel oil

    Lubrication oil

    Fuel oil

    Heavy fuel oil

    SAE30, 40

    Detergence oil

    Steam turbine oil

    Kinematical viscosity(mm2/s)

    1.9-5.5

    5.5-24

    120

    180

    380

    100-120

    61.2-74.8

    40°C

    50°C

    40°C

    40°C

    Density/(kg/m3)(20°C)

    < 900

    900-991

    880-900

    < 900

    Separating temperature

    (°C)

    normal temperature, 40-60 best

    90-98

    80-95

    Recommended capcity

    (l/h)

    17500

    14000

    7700-8400

    6300-7000

    4900-5600

    7000-8400

    3500-4200

    11200-11900

    Note: Reserve the right to change specifications without prior notification.


    More pictures
