2000L Disc Stack Centrifuge Machine For Waste Oil Separator
Product overview
Model PDSD2000-F separator is mainly used to remove water and mechanical impurities from diesel oil, lubricating oil and other mineral oil in marine diesel engine unit and land-used diesel generator unit of power station so as to reduce wear of the diesel engine and other machine, and prolong engine life. The model is also used to separate two unsolvable liquids with different specific gravity or remove small amount of solid particle from liquid.
The machine has the advantages of high efficiency, low oil
consumption, convenient operation and economic
maintenance cost.The clear oil and dirty water are let out freely, the sludge is
discharged manually.
The machine is one kind of rotary machine with high speed, After
accurate dynamic balancing, it can run for long time
with low vibration, safety and security.
The design, product and acceptance are conformed to the standard of
GB/T5745 “Marine Disc Separator”.
Advantage
1.Manual type slag removal unit
2.Modular design
3.Automatic control
Technical parameter
Discharging type | Full discharge | |
Max capacity | L/h | 2000 |
Motor power | Kw | 4 |
N.W. | kg | 620 |
Packing Dimension | L × W × H (mm) | 1000*920*1300 |
Other oil capacity reference chart
oil types | fuel oil | lubrication oil | |||||||||
fuel oil | heavy fuel oil | SAE30,40 | detergence oil | steam turbine oil | |||||||
kinematical viscosity(mm2/s) | 1.9-5.5 | 5.5-24 | 120 | 180 | 380 | 100-120 | 61.2-74.8 | ||||
40°C | 50°C | 40°C | 40°C | ||||||||
density/(kg/m3)(20°C) | less than 900 | 900-991 | 880-900 | less than 900 | |||||||
separating temperature (°C) | normal temperature,40-60best | 90-98 | 80-95 | ||||||||
recommended capcity (l/h) | 2400 | 2000 | 1100-1200 | 900-1000 | 700-800 | 1000-1200 | 500-600 | 1600-1700 |
