    Newly Built Food Grade Continuous Milk Disc Stack Centrifuges

    Ask Lasest Price
    Brand Name : Peony
    Model Number : PDSM-DN
    Certification : ISO
    Price : USD20000~80000/SET FOB SHANGHAI
    Payment Terms : TT,.LC, Western Union
    Supply Ability : 100 sets per month
    Delivery Time : 60-90 days after down payment
    • Product Details
    • Company Profile

    Newly Built Food Grade Continuous Milk Disc Stack Centrifuges

    Newly Built Food Grade Continuous Milk Disc Stack Centrifuges



    Description

    PDSM-DN series 3-phase disc separator is a milk cream separator, mainly used for milk purifying. It is also used for similar materials for the Liquid-Liquid-Solid three-phase separation, such as coconut water, etc.


    The machine is one kind of rotary machine with high speed. After accurate dynamic balancing, it can run for a long time with low vibration, safety and security.

    Advantages
    1. The castings are formed in one piece by using the digital control processing equipment from Germany, see attached picture. Its strength and precision are higher than those from many other suppliers in China, who just use a lathe and after many steps and welding, get the parts.
    2. At least 48 hours of gravity elimination for the welding parts; this step is omitted by many other suppliers.
    3. Advanced structure for slag discharge, increase product yield, reduce material loss, prolong service life, and easy to maintain. While others still use spring which is easy to deform.
    4. Slag discharge is PLC controlled, realizing part discharge and full discharge combined together, to avoid slag accumulating.
    Single Value Analysis

    1. Peony adopts SKF bearing, which is consistent with Alfa, Westfalia.
    2. Alfa and Westfalia only provide clients with the bearing and the gear in the overhaul package(need to buy separately) while Peony has a more sufficient attachment supply.

    3. Peony never reduces the number of spare parts and tools for users buying many sets of the same model machine. (unless the customer put forward in specially).

    4. Regular spare parts are all in stock in Peony’s company.
    Main Technical Specification
    ModelPDSM1000-DNPDSM1000-DNPDSM5000-DNPDSM10000-DN
    Capacity (L/h)10003000500010000
    Motor power (KW)47.51518.5
    Discharging typeVariable capacityVariable capacityPart dischargingSmall valve discharging

    Output pressure of

    clear liquid (MPa)

    ≤0.1≤0.1≤0.1≤0.2
    Net weight (KG)53663510001250

    Overall dimension

    L × W × H (mm)

    885x854x10821120x850x12371270×1188×1560

    1563x1382x1780




    More pictures







    Our service

    1. 12 months guarantee period from machine arrival date.
    2. Abundant spare parts in stock are available to provide.
    3. Our technicians could be dispatched for overseas service.
    4. 7*24 hours technical consultation.
    5. Your workers could get trained both in our factory and yours.
    6. Routine tracing till the machine work properly will be done timely.
    7. We will remind you to do normal maintenance.
    8. Your suggestions or any comments & reflection would be treated as a priority.
    9. Marketing team will visit you during our visit to your country if you require.
