    Horizontal Continuous Decanting Centrifuge Separator With Solid Control Systerm

    Ask Lasest Price
    Brand Name : Peony
    Model Number : PDC
    Certification : ISO9001& ISO14001
    Payment Terms : TT,.LC
    Supply Ability : 60sets per month
    Delivery Time : 60-75 days after down payment
    Price : USD20000-100000/SET
    • Product Details
    • Company Profile

    Horizontal Continuous Decanting Centrifuge Separator With Solid Control Systerm

    Horizontal Continuous Decanting Centrifuge Separator With Solid Control Systerm


    Competitive Advantages

    • automatic continuous operation
    • Water level adjustable
    • Highest efficiency and lowest power consumption
    • PLC control
    • Screw conveyor full tiled.

    Specifications


    Model

    Diameter

    (mm)

    Bowl Speed

    (rpm)

    G-force

    Capacity

    (m3/h)

    Main Power

    (kw)

    Weight

    (kg)

    Overall Size

    (L × W × H)

    (mm)

    PNX-409250550034930.2~215/410202500 × 650 × 760

    PNX-414

    355400031751~1018.5/7.52035

    2765 × 920 × 1060

    PNX-41635540003175

    1~15

    18.5/7.52122

    3065 × 920 × 1060

    PNX-41835540003175

    1~25

    22/7.52222

    3365 × 920 × 1060

    PDC-16.542030002113

    10~30

    55/154600

    4080 ×1100 × 1420

    PDC-17-442036003042

    3~15

    30/7.55165

    3331 × 990 × 1066

    PDC-18-4.445033002739

    10~20

    37/112739

    4000 × 1120 × 1239

    PDC-2050032002860

    5~45

    55/114400

    4489 × 1160 × 1350

    PDC-2154028002366

    15~50

    45/155290

    4587 × 1285 × 1368

    PDC-2462032003555

    15~60

    Hydraulic station 90

    8000

    4650 × 2010× 1200

    PDC-28HH72022001975

    15-80

    110/379393

    4800 ×1350 × 1500

    PS: The above parameters will be subject to the final technical agreement.


    Structure


    Horizontal Continuous Decanting Centrifuge Separator With Solid Control Systerm


    eparation principle


    Taking advantage of the principle that the light liquid, heavy liquid and solid phase, with different density and mutually insoluble in the mixed liquid, gain different sedimentation speed in the centrifugal force field or gravity force field, separating stratification or causing the solid particles in the liquid to deposit can be achieved. In the gravity force field or centrifugal force field, the light liquid phase, the heavy liquid phase and the solid phase with different density and mutually insoluble in the mixed liquid, respectively gain different sedimentation speed, and thus separate and stratify. In the gravity force field it is called gravity separation, while in the centrifugal force field it is called centrifugal separation.


    Applications


    Drilling mud is an integral part of most drilling operations,it is also called drilling fluid, there are some solids suspended in the fluid Peony Decanter Centrifuge can provide solid-liquid separation technology to your drilling mud application, enabling reuse of the material and more efficient and cost-effective disposal.We have our special design and collocation decanter centrifuge for oilfield and industrial solids control, drilling fluid / mud cleaning and process water treatment.

    Peony Decanter centrifuges are used to process water-based and oil-based drilling fluids. Oilfield decanter centrifuges mechanically increase the gravitational force exerted on the liquid and solids mixture present in the mud system. We can apply over 3,000 G-forces machine to separate the particles in the fluid. Peony Decanter centrifuges have wide process capacity to meet all ranges as per drilling program.It is commonly and widely used used for oilfield and gas well operations providing efficient solids control while significantly reducing the operator's total mud cost and minimize waste disposal volumes.
