Diesel Oil Disc Separator - Centrifuge , Solid Liquid Separation Equipment

Description

Model PDSD8000 separator is mainly used to remove water and mechanical impurities from diesel oil, lubricating oil and other mineral oil in marine diesel engine unit and land-used diesel generator unit of power station so as to reduce wear of the diesel engine and other machine, and prolong engine life. The model is also used to separate two unsolvable liquids with different specific gravity or remove small amount of solid particle from liquid.

The machine adopts automatic control, and has the advantages of high efficiency, low oil consumption, convenient operation and economic maintenance cost.

The clear oil and dirty water are pumped out by centripetal pump, the sludge is discharged automatically and fully.

The machine is one kind of rotary machine with high speed. After accurate dynamic balancing, it can run for long time with low vibration, safety and security.

The design, product and acceptance are conformed to the standard of GB/T5745 “Marine Disc Separator”.

Main Technical Specification for single machine

Automatic control system

Water Control: Automatic control unlocking water, sealing water and water-seal/water switching.

Pneumatic Control: Filter and adjust compressed air, control three-way changeover pneumatic valve.

Temperature Control: Automatic control the temperature of the oil line, also control separately

or with electric control cabinet at the same time.

Buzzer Control: Monitor oil temperature, pressure, over loading, non-discharging and leaking,

and Offer a group of passive contactor stretching out to control panel.

The whole unit consists of

1. Separator
2. Electric control box
3. Oil feed pump
4. Oil filter
5. Pneumatic three-way valve
6. Ball valve
7. Pressure gauge
8. Vacuum gauge
9. Stop-check valve
10. 2/2 Solenoid valve
11. 3/2 Solenoid valve
12. Air reduction pressure valve
13. Brass filter ball valve
14. Water pressure reducing valve
15. Temperature sensor
16. Liquid level switch
17. Sludge pump
18. Skid

Certificate

Value Analysis

1. According to the requirements of each classification society, all modules are equipped with oil leak alarm and high temperature alarm.
2. Oil.hydraulic, pneumatic control part adopts the Brand Baode (Germany).

3. Heater adopts brand SWEP (Germany).

4. Pressure control adopts Korean products or products

5. Screw pump is used instead of gear pump.

6. All equipped with automatic temperature control device (Made by the RTK production in Germany or made in China)
7. The main electrical components of standard electrical control box are produced by Schneider company while PLC is produced by Siemens or Mitsubishi.
8. The complete sets referred above are all Peony's production of automatic Standard Controls and we certainly can modify the configuration list according to customers’ specified requirements.

Peony organizes the model selection question as below

1)How many kinds of the oil can you separate?
This series separator is widely used for kinds of oils, especially for the Marine diesel oil and the similar

oil, such as light fuel oil, heavy fuel oil, lubrication oil, steam turbine oil, detergence oil, engine oil etc

2)How can you select the suitable capacity?
Different oil has different capacity, our 1500L, 2000L, 3000L, 4000L, 5000L, 6000L, 8000L ,

10000L capacity is for the Marine diesel oil 0# as sample. It also depends on the viscidity, temperature,

and for all the capacity model, we have an oil characteristic sheet to help our customer to find out

what their oil is, and what capacity their oil belongs to.

3) Is your separator self cleaning?
We have 3 types discharge means according to different material and customer's requirements,

we have self cleaning model and manual cleaning model.
1. Manual discharge model for the oil with very less solid component
2. Full discharge model for the big capacity treatment and a little solid component
3. Partly discharge model for the bigger capacity treatment and more solid component

4).Variable discharge model

No.full discharge type and partially discharge type are both self cleaning model.
4)Will you help us to select the model?
Yes,you can select the model by yourself, or as long as you provide your material characteristic,

we have professional engineer team to help you select the suitable machine

5)Do you only have the single machine or the unit?
Both we have.

More pictures
