Top Discharge Type Plate Top Discharge GMP Centrifuge with Explosion-proof Motor

Description

The drum of the centrifuge in the Model PPTD flat-plate centrifuge is designed with a feeding pipe on the hermetic closure casing. The material to be processed is introduced into the drum through this feeding pipe. Once inside the drum, the material is subjected to the centrifugal force field.

During operation, the liquid phase of the material passes through the filter medium and is discharged from the machine. On the other hand, the solid-phase material is retained inside the drum. When the machine is stopped, the solid-phase material can be discharged from the top of the drum.

The Model PPTD flat-plate centrifuge offers several notable features. It runs smoothly, ensuring efficient operation. It is also designed to be easy and convenient to operate. The centrifuge allows for feeding, washing, and dehydrating processes to be carried out under the state of hermetic closure, meaning a sealed environment is maintained during these operations.

This model incorporates a flat-plate counterweight and a high-viscosity damping vibration reducer to absorb vibrations. This design eliminates the need for traditional hanging supports and ensures stable operation with reduced vibration.

One advantage of the Model PPTD flat-plate centrifuge is that it does not require a foundation for installation. This simplifies the installation process, as no dedicated foundation is needed to support the centrifuge.

Features

• No base installation, without traditional tripod type hanging structure and simplifies the installation process
• Reasonable design and new and simple structure
• Basic platform is the work operation platform
• Reduced labor and high efficiency
• Simple operations and easy cleaning
• Outside and inside surface of rotary drum is polished
• All of fasteners are made of stainless steel
• Transmission section is sealed with stainless steel
• Airtight packing is made of silicone rubber
• Equipped with CIP system, the whole machine meets GMP hygienic standards11) Imported high-viscosity liquid damping agent shock isolator ensures that no vibrations will affect the base of the unit, the ground and neighboring equipment
• Outer case has a fully opening cover
• Especially suitable for solid-liquid separation of poisonous, harmful mediums
• With open-cover, overheating, overloading and over-current protection
• Full sealing, explosion-proof and very clean
• Adopts explosion motor frequency driving and static-proof V-belt
• When equipped with nitrogen protection, the machine is suitable for solid-liquid separation of combustibles or explosive

Applications

It is applicable to the filtrating of suspension containing granules and can also be used for the ne granules as well as toxic and flammable materials. It has found wide applications in such trades as chemical, pharmacy, food, light industry, etc. for example: gypsum, thiamine, mirabilite, ferric sulfate, copper sulfate, nickel sulfate, potassium chloride, acetic acid, borax, soda, rubber additive, dye, plastic raw material, soap, grease, all kinds of resins, food salt, sodium glutamate, food additives, starch sugar-making, vitamins, antibiotics, herbicide, insecticide, the dehydration of such mineral fines as copper, zinc, aluminum, etc.
