Description

Model PTDM centrifuges are three-column top discharge, intermittent operation filtrating equipment. The material is fed into the drum at the top; under the action of the centrifugal force field., the liquid-phase passes through the filter medium and the discharged out of the machine, while the solid-phase material is retained inside the drum and, after the machine is stopped, the material is discharged from the top. The centrifuge has such features as simple structure, easy operation, no easy breakage of material as well as good versatility.

The surface of the parts contacting the material is smooth, flat, easy to clean (or sterilize), corrosion-resistant. Non-reactive with medication and non-adsorptive. The centrifuge’s drum, class liner bag and exterior and interior of the casing have all undergone polishing treatment.The open hinged cover facilitates the discharging and maintenance. With the cover equipped with feed pipe, washing pipe, explosion proof lamp, wide angle vision glass, etc. (depends on client's needs) It is possible to monitor the whole process of feeding, separating and washing.

Model PTDM centrifuge is with foundation and match ex-motor.

Specifications

Working principles

1) Airtight equipment2) The material is fed from the upper into the rotary drum
3) Under the centrifugal force function, the liquid passes through the filtering medium and discharges out of the machine
4) The solid is left in the rotary drum
5) After the machine is stopped, unload the material
6) Advantages: large capacity, high efficiency, simple operation, fast unloading, good guarding function, clean surrounding

Applications

The centrifuge is applicable to the separating of the suspension containing solid-phase granules with the diameter than 0.01 mm. The solid may be in the forms of granules, crystals or fiber. It is also applicable to the dehydrating of goods in pieces (such as yarn bundles, textile, etc.) it has found wide applications in such trades as chemical, pharmacy, food, light industry. etc. for example :gypsum, thiamine, salt cake, ferric sulfate, cooper sulfate, food additives, starch sugar making, vitamins, antibiotics, herbicide, insecticide, the dehydration of such mineral fines as copper, zinc, aluminum, etc.

Basic Information

Zhangjiagang City Peony Machinery Co., Ltd., founded as a special producing enterprise of separating equipment in 2008, is the well-known manufacturer and service provider of separation and filtration in China. Peony dedicated to solving the solid-liquid, liquid-liquid separation problems for clients all over the world and providing separating and filtering mechanical products with convenient operation, high efficiency, reliable quality, and excellent service worldwide. Being a group corporation, Peony has 3 producing bases in China - Zhangjiagang, Nanjing, and Hangzhou city.

Products

As the professional supplier of separating and filtering equipment, we produce basket centrifuges, decanters, and disc separators starch product line, and sell the auxiliary equipment such as clarify equipment, filters, pumps, etc. These 25 series of more than 150 products are self-development of Peony and have attained national patent. Those products and relevant auxiliary equipment are widely used in chemical, petroleum, pharmacy, mining, food, beverage industry, and environmental protection.

We own various kinds of inspection and testing facilities with a value over USD10million, now,16 testing tables,6920 gear testing center, X-ray detecting machine, high-speed dynamic balancing machine, ultrasonic flaw detection machines, etc, we are equipped with complete testing, inspection, analysis control system, advanced testing machines and simulative working condition test table and automatic control testing system, which guarantees our new product research, processing validation, and quality.

We have strongly equipped the robust and precise processing machines from Germany, Italy, England, and our domestic famous brand, here, I'd like to list several of them for your reference.
200 Numerical Control Boring and Milling Machine TK6920
160 Numerical Control Boring and Milling Machine TK6916
Italian PAMA Numerical Control Boring and Milling Machine
80T CNC Lathe
40 T CNC Lathe
2.5m Merry Go Round Machine C525E
Z100 Radial Drill
Numerical Controlled Vertical Milling Machine
Underwater Plasma Cutting Center
CNC Machining Center


We harvested great achievement these years, and turnover reaches to 380million RMB in
the year 2013, and we expect to carry out 500million RMB in 2015.

Welcome all who are engaged in the separation and filtration to work with us, and we are also looking for qualified world wide agents to provide better service and deep marketing.

Worldwide Network

Our products have spread all over the world and are applied over 35 countries and regions, for example, America, Germany, Italy, Sweden, Canada, Singapore, Australia, Brazil, Russia, India, Middle East, and Southeast Asia, etc. To provide flexible and qualified technical service to resolve any maintenance issue in the shortest time possible, now we have established agents in many countries such as Brazil, Colombia, Latin America, Bangladesh, Southeast Asia, etc.
