    Sulzer Metal Screen Basket Centrifuge Table Salt Processing Machine

    Ask Lasest Price
    Brand Name : Peony
    Certification : ISO
    Model Number : PP
    Price : USD24000-80000/SET FOB Shanghai
    Delivery Time : 60-90 days after receive the deposit
    Payment Terms : T/T,L/C, West Union
    Supply Ability : 50 sets/month
    • Product Details
    • Company Profile

    Sulzer Metal Screen Basket Centrifuge Table Salt Processing Machine

    Sulzer Metal Screen Basket Centrifuge Table Salt Processing Machine


    Quick skimming


    Application: Salt Dewatering Centrifuge

    Bearing: SKF

    MOC: SS304, SS316, DUPLEX SS

    Motor defends degree: IP54/F1

    Electrical elements: Famous brand

    Advanced technology: Sulzer

    Separation affection: Moisture in the cake less than 4%


    Sulzer Metal Screen Basket Centrifuge Table Salt Processing Machine


    Description


    The PP Sulzer Double Stage Salt Centrifuge is a type of perforated basket centrifuge that is both continuous and effective. To begin the process, the mixture to be separated is fed through the feeding pipe and the distributor, which then distributes the mixture evenly into the first stage basket. The centrifugal force causes most of the mother liquor in the feed to depart through the sieves and into the liquor-collecting casing, where it is discharged out of the machine. The first stage basket rotates and reciprocates, pushing the formed product cake into the second stage basket. The cake is slowed down by the centrifuge and acted on by more centrifugal force, which guarantees the desired humidity of the cake. The cake is continuously discharged from the basket. For high purity of the solid product, the centrifuge can perform an effective washing. If necessary, the washing agent and the mother liquor can be discharged separately.

    Sulzer Metal Screen Basket Centrifuge Table Salt Processing Machine

    Sulzer Metal Screen Basket Centrifuge Table Salt Processing Machine


    Technical Parameters of PP-40


    Equipment

    2-stage pusher centrifuge

    Spec.

    PP-40

    Qty

    set

    Technical parameters

    1

    Basket diameter

    290/360 mm

    2

    Basket Rotate Speed (Max)

    2500r/min

    3

    Stroke of Pusher Mechanism

    40-80times/min

    4

    First, second stage mesh aperture (as per the material)

    mm, mm

    5

    Separation Factor

    586-728

    6

    Main motor

    Spec/Power

    11-15KW



    Installation type

    Horizontal



    Protection class

    IP54/F1



    Electrical power

    3 phase 380V/50Hz AC

    7

    Oil pump motor

    Spec/Power

    5.5-7.5KW



    Installation type

    Horizontal



    Protection class

    IP54/F1



    Electrical power

    3 phase 380V/50Hz AC

    8

    Oil pump

    Spec.

    NB4C100F



    outflow

    100ml/turn



    Maximum pressure

    2.5Mpa

    9

    Overall size

    2346mm×1090mm×1006mm

    10

    Weight

    2600kg

    11

    Shell type

    open

    12

    Output

    3T-5T/h(sea salt)

    13

    Moisture content after separation:

    3-4%(sea salt)

    14

    Object processed

    Mineral salt/Sea salt


    Technical Parameters of PP-50


    Equipment

    2-stage pusher centrifuge

    Spec.

    PP-50

    Qty

    set

    Technical parameters

    1

    Basket diameter

    438/500 mm

    2

    Basket Rotate Speed (Max)

    2000rpm

    3

    Stroke of Pusher Mechanism

    40-80times/min(can be adjusted)

    4

    First, second stage mesh aperture (as per the material)

    mm, mm

    5

    Separation Factor

    1119

    6

    Main motor


    Spec/Power

    45KW

    Installation type

    Horizontal

    Protection class

    IP54/F1

    Electrical power

    3 phase 380V/50Hz AC

    7

    Oil pump motor


    Spec/Power

    22KW

    Installation type

    Horizontal

    Protection class

    IP54/F1

    Electrical power

    3 phase 380V/50Hz AC

    8

    Oil pump

    Spec.

    SNE/A280

    outflow

    480ml/turn

    Maximum pressure

    2Mpa

    9

    Overall size

    3660mm×1420mm×2078mm

    10

    Weight

    4400kg

    11

    Shell type

    open/seal(can be select)

    12

    Output

    ≥12T/h(sea salt)

    13

    Moisture content after separation:

    4%(sea salt)


    Technical Parameters of PP-60


    Equipment

    2-stage pusher centrifuge

    Spec.

    PP-60

    Qty

    set

    Technical parameters

    1

    Basket diameter

    560/630 mm

    2

    Basket Rotate Speed (Max)

    1360 r/min

    3

    Stroke of Pusher Mechanism

    70-80 times/min

    4

    First, second stage mesh aperture (as per the material)

    mm, mm

    5

    G-force

    570-642

    6

    Main motor


    Spec/Power

    55KW

    Installation type

    Horizontal

    Protection class

    IP54/F1

    Electrical power

    3 phase 380V/50Hz AC

    7

    Oil pump motor


    Spec/Power

    30KW

    Installation type

    Horizontal

    Protection class

    IP54/F1

    Electrical power

    3 phase 380V/50Hz AC

    8

    Oil pump

    Spec.

    NB5D140F

    outflow

    140ml/turn

    Maximum pressure

    8Mpa

    9

    Overall size

    3127mm × 1700mm × 1955mm

    10

    Weight

    4860kg

    11

    Shell type

    open

    12

    Output

    ≥15T/h (Mineral salt)

    13

    Moisture content after separation:

    ≤3%
