Verticle Type Self cleaning Coconut Oil Separator Centrifugal Separator with SKF Bearing

ZHANGJIAGANG CITY PEONY MACHINERY CO.,LTD
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap Verticle Type Self cleaning Coconut Oil Separator Centrifugal Separator with SKF Bearing from wholesalers

    Buy cheap Verticle Type Self cleaning Coconut Oil Separator Centrifugal Separator with SKF Bearing from wholesalers
    • Buy cheap Verticle Type Self cleaning Coconut Oil Separator Centrifugal Separator with SKF Bearing from wholesalers

    Verticle Type Self cleaning Coconut Oil Separator Centrifugal Separator with SKF Bearing

    Ask Lasest Price
    Brand Name : Peony
    Certification : ISO9001&ISO14001,CE
    Model Number : SWDB204SD-01
    Delivery Time : 45days
    Payment Terms : TT. LC
    Supply Ability : 100sets per month
    • Product Details
    • Company Profile

    Verticle Type Self cleaning Coconut Oil Separator Centrifugal Separator with SKF Bearing

    Self cleaning Coconut Oil Separator Centrifugal Separator with SKF Bearing

    Structure Features

    1.The material of drum body, drum cover and valve is high strength stainless steel, the Moc of other parts are all high quality, anti-corrosion SS304, the separator shell employ SS304.


    2.Drive structure support use SKF bearing, by employing optimal design to reduce the height of the drum’s center of gravity. It can effectively lower the vibrational level of the whole separator, improve the reliability of the equipment and increase the stability of the separator.


    3.In the dismounting and maintenance, the parts of drum can be hoisted integrally,thus make the dismounting of main lock ring more convenient, saving both time and labor, easy to install the drum.


    4.The separator runs supercurrent, it will send warning signals and be stoped if the machine overload, to make the separator runs safely.


    5.The separator has a less vibration and more stability through price dynamic balance of the drum.


    6.The separator adopts separation factor technology. It can separate product that is hard to separate, meanwhile, the machine has light volume and use the small volumeto get big capacity and high separation efficiency.


    7.The separator adopts advance belt drive, improving the reliability and maintainabilityof the separator, and decreasing cost of spare parts.

    Pictures
    Verticle Type Self cleaning Coconut Oil Separator Centrifugal Separator with SKF Bearing
    Main Technical Specification:

    Capacity

    < 1000L/h

    Working diameter of bowl

    Φ230mm

    RPM

    11200rpm

    Discharge type

    Self-cleaning (PLC control)

    Vibration

    ≤2.8mm/s

    Noise

    ≤85dB(A)

    Starting Mode

    Frequency Startup

    Driving Mode

    Belt Drive

    N.W.

    371kg

    Dimension (L*W*H)

    930×750×1050mm

    Motor

    Power

    7.5kW

    Single Value Analysis
    1. Peony adopts SKF bearing , which is consistent with Alfa, Westfalia.

    2. Alfa and Westfalia only provide clients with the bearing and the gear in the overhaul package(need to buy separately) while Peony has more sufficient attachment supply.

    3. Peony never reduce the amount of spare parts and tools for users buying many sets of the same model machine. (unless the customer put forward in specially).

    4. Regular spare parts are all in stock in Peony’s company.

    Pictures
    Verticle Type Self cleaning Coconut Oil Separator Centrifugal Separator with SKF Bearing
