    Planetary Gearbox Automatic Control Drilling Mud Centrifuge with Solid Bowl

    Ask Lasest Price
    Brand Name : Peony
    Certification : ISO
    Model Number : PDC, PNX
    Delivery Time : 75-90 days after down payment
    Payment Terms : TT,.LC, Western Union
    Supply Ability : 60 sets per month
    Price : USD25000-100000/SET FOB Shanghai
    • Product Details
    • Company Profile

    Planetary Gearbox Automatic Control Drilling Mud Centrifuge with Solid Bowl

    Planetary Gearbox Automatic Control Drilling Mud Centrifuge with Solid Bowl


    Competitive Advantages

    • Automatic continuous operation
    • 360 degree discharge
    • Water level adjustable
    • High efficiency and low power consumption
    • PLC control
    • Screw conveyor: tiled


    Separation principle

    Taking advantage of the principle that the light liquid, heavy liquid and solid phase, with different density and mutually insoluble in the mixed liquid, gain different sedimentation speed in the centrifugal force field or gravity force field, separating stratification or causing the solid particles in the liquid to deposit can be achieved.


    Specifications


    Model

    Diameter
    (mm)

    Speed (rpm)

    Length
    (mm)

    G-force

    Capacity
    (m3/h)

    Main motor Power
    (kw)

    Assistant motor power
    (kw)

    Weight
    (kg)

    Overall Size
    (L × W × H)
    (mm)

    PNX-414

    355

    4000

    860

    3175

    1~10

    22

    7.5

    2035

    2765 × 920 × 1060

    PDC-14

    355

    4000

    1160

    3175

    1~15

    22

    7.5

    2122

    3065 × 920 × 1060

    PNX-418

    355

    4000

    1460

    3175

    1~25

    22

    7.5

    2222

    3365 × 920 × 1060

    PDC-17-3

    420

    3600

    1290

    3042

    1~20

    22

    7.5

    2100

    2931 × 990 × 1066

    PDC-17-4

    420

    3600

    1680

    3042

    2~35

    22

    7.5

    2230

    3331 × 990 × 1066

    PDC-18-3.8

    450

    3500

    1720

    3080

    4~40

    37

    11

    3560

    4100 × 1120 × 1239

    PDC-18-4.4

    450

    3300

    2000

    2739

    4~50

    45

    Hydraulic

    3655

    4000 × 1120 × 1239

    PDC-20

    500

    3200

    2000

    2860

    5~45

    55

    11

    4213

    4489 × 1160 × 1350

    PDC-21

    540

    2800

    2000

    2366

    5~50

    55

    15

    5290

    4587 × 1285 × 1368



























    More pictures






    Guarantee


    Peony Centrifuge is committed to producing high-quality machinery and equipment, as well as providing facility construction services. We aim to provide the best possible products while ensuring customer satisfaction. We believe in rewarding our customers with superior quality products in return for their trust and interest. Our team is dedicated to taking one more step forward by providing infinite services and a strong commitment to our customers.
